STRAPPING EQUIPMENT FOR WIRE COILS AND ROLLED PRODUCTS
Automated strapping equipment for long steel products TF-400-A
Strapping equipment technical specification
| Parameter | Unit | Value |
|---|---|---|
| Overall dimensions (L × W × H) | mm | 4424 × 1888 × 1100 |
| Guide track inner diameter | mm | ≈ Ø 700 |
| Tie wire diameter | mm | Ø 6.3 ~ 7.0 |
| Cooling type | - | Air cooling |
| Control voltage | - | 24 V DC |
| Tie wire material | - | Q195 - Q235 steel |
| Hydraulic pump flow rate | l/min | 100 |
| Strapping cycle time | s | ≤ 14 |
| Permissible bundle diameter | mm | Ø 150 ~ 450 |
| Hydraulic system operating pressure | bar | ≈ 100 ~ 120 |
| Electric motor power | kW | 11 |
| Maximum tension force | N | 10000 |
