CONTROL ROPE. CONDUCTIVE CABLE
GENERAL PURPOSE CONTROL CABLES
Product | Design | Construction | Diameter, mm | Normative document | Intended use of product |
One lay stainless steel ropes type ЛК-О | 1х7 (1+6) | 0.30-2.00 | TU 14–173–46–2006 ТУ 14–173–132–2003 | In car alarm systems, mirrors of VAZ new modifications | |
Zinked steel ropes | 1х12 | 1.00-1.80 | TU 14-178-429-01 | Used in hand brakes, clutches, accelerators, speedometers, hood opening mechanisms, ovens, etc. | |
One lay zinked steel ropes type ТК | 1х19 (1+6+12) | 0.80-6.00 | GOST 3063-80 DIN 3053 | Used in cable ways, automobile construction, as wire lines lightning-protection, wire-braced and supporting cables. | |
One lay zinked steel ropes type ТК | 1х37(1+6+12+18) | 2.50-6.00 | GOST 3064-80 DIN 3054 | Used in cable ways and cable cranes. | |
Two lay zinked stainless steel ropes type ЛК | 7х7 | 0.80-6.00 | GOST 3066-80 DIN 3055 | Used in automobiles, computing technics, cable ways, as wire-braced, rigging cables and cables for cargo towage | |
Zinked stainless steel ropes | 7х19 | 1.50-6.00 | GOST 3067 DIN 3060 | In conveyer belts | |
Steel ropes 8x7 + 1x19 | 8x7 + 1x19 | 1.50-2.00 | In car window regulators. |
CONDUCTING CABLES
Specification
Isolation | High-density polyethylene HDPE | Law-density polyethylene LDPE | Polyvinylchlorid PVC | Polypropylene PP | Peat-oil mixture POM | PA6 | Nylon resin |
Electric conductor | + | + | + | + | |||
Outer covering | + | + | + | + | + | + |
Technical specifications
Specification, mm | Outer diameter, mm | Diameter of cable without isolation, mm | Inner diameter, mm | Construction (wire diameter+number) |
4.20 5.00 | 4.00-4.20 4.80-5.00 | 3.10-3.30 4.00-4.20 | 1.50-1.70 1.90-2.10 | 0.50×17 0.60×18 /0.50×21 |
8.20 9.00 | 8.00-8.20 8.80-9.00 | 6.10-6.30 7.10-7.30 | 2.60-2.80 3.60-3.80 | 0.80×21 0.80×24 |
FLEXIBLE ELECTRIC CABLES
Used for power transmission. Construction: |
Specifications
Diameter, mm | Diameter tolerance, mm | Layers quantity | Vibration | Max. Positive angle of torsional deformation | Min. Positive breaking tension, N.m | Rough weight, kg/100 m |
2.00 | 0.02 | 3 | --- | 150 | 0.60 | 1.80 |
2.40 | 3 | 150 | 0.60 | 2.60 | ||
3.15 | 4/5 | 2.0 км/ч. | 120 | 0.80 1.00 | 4.60 4.60 | |
3.20 | 4 | |||||
3.60 | 4 | --- | 100 | 2.00 | 5.80 | |
3.70 | 0.05 | 4/5 | 100 | 2.20 | 6.30 | |
3.80 | 4/5 | 90 | 2.50 | 6.50 | ||
4.00 | 4 | 80 | 2.80 3.00 | 7.20 8.80 | ||
4.38 | 5 | |||||
4.45 | 5 | 70 | 5.00 5.20 5.20 | 9.10 9.70 10.20 | ||
4.60 | 5 | |||||
4.70 | 5 | |||||
4.80 | 4 | 55 | 5.80 | 10.40 | ||
5.00 | 4/5/6 | 50 | 6.30 6.50 | 11.30 12.70 | ||
5.25 | 3 | |||||
6.00 | 4/5/6 | 45 | 8.50 | 16.60 | ||
6.20 | 4/6 | 35 | 10.00 | 17.30 | ||
7.90 | 5 | 24 | 12.00 15.00 | 28.70 28.80 | ||
8.00 | 4/6 |
